Deutz Engine Performance and Installation

As the heart of construction machinery vehicles, the engine determines the overall power, economy and stability of the vehicle. Deutz engine is also highly concerned in the industry, at present, Deutz engine has been widely used in all kinds of construction machinery and equipment, millions of pump trucks to hundreds of thousands of mixer trucks, can see its figure. So, Deutz engine in the end is good? And how should it be installed? Take a look!

First of all, from the performance point of view, the Deutz engine has high fuel economy and power performance, which makes the vehicle in the operation process can be more efficient, energy saving, but also can provide more excellent power performance.

Secondly, in terms of technology, Deutz engine adopts advanced technologies, such as double VVT, double valve, double turbocharging, variable valve timing system and so on, which make the engine's power performance more excellent and fuel economy higher. In addition, Deutz engines also adopt advanced anti-vibration technology, which effectively reduces the noise and vibration of the engine when it is running at high rpm, and improves the driving comfort and the service life of the engine.

Overall, Deutz engines are highly recognized in the market, with high cost performance and market competitiveness. If you are considering buying an engine, then Deutz engines are definitely an option worth considering.Keluo Construction Machinery sells a wide range of old and new Deutz engines, which are not only more affordable, but also of guaranteed quality and will last for a long time. You can get the products that you need the most, and the ones that are most suitable for you, right here on the official website of Keluo Construction Machinery.

So, how to install the Deutz engine bought on the official website of Keluo Construction Machinery? Below I will take the Deutz BF4M2012C engine as an example and explain it briefly for you.

Step 1: Disassemble. Loosen the main oilway stabilizer valve and drain the diesel fuel inside the main oilway to prevent it from flowing into the crankcase. It is important to note during disassembly that the valve chamber must be removed, and then the high-pressure fuel line must be removed and the injector connectors must be sealed to prevent impurities from getting in. When disassembling the mechanical actuator also pay attention to the direction of disassembly to avoid prying and prevent damage. Disassemble the rotary engine until the tappet of the monoblock pump to be disassembled is in the lowest position to release the spring pressure to put the spring in the maximum free position to prevent the monoblock pump from popping out and being damaged.

Step 2: Cleaning. ①Clean the monoblock pump without any impurities, especially the oil inlet, otherwise it will cause the plunger to wear.

② Clean the monobloc pump mounting holes and oil channels to make sure there are no impurities.

Step 3: Installation. ①First, use the special tool to fix the rack to the flameout position, which is a necessary step to unify the oil volume and flameout position of the monoblock pump, and then remove it until all the installation work is finished. Rotate the tappet of the cylinder where the monobloc pump is to be installed to the lowest position so that it can be installed easily and without error. ③Adjust the fork of the monobloc pump to the OFF position. ④Install the cushion of the monobloc pump into the tappet, keep it flat, and then remove the monobloc pump. ⑤ Then tighten the two screws of the cover at the same time and press down the monobloc pump, but do not tighten them. ⑥ Lock the two nuts to the specified torque without tilting the lever. And follow this method to install the monobloc pumps of other cylinders. ⑦ Check with a depth gauge if the stroke of the monobloc is within the standard range, if not, check again if the monobloc pump is installed correctly. ⑧ Finally, install the actuator, valve cover, and high pressure fuel line, install the standard sequence and tighten to the standard torque, so that you can test the machine.

Do you want to know more about Deutz Engine maintenance, troubleshooting or specifications?Construction Machinery has all kinds of information on its official website.
